Skywalk JOIN’T5 TANDEM PARAGLIDER
Skywalk Join’t5 tandem paraglider is the result of close collaboration with experienced tandem pilots. Available in three sizes, it covers an impressive weight range from 100 to 240 kg, making it versatile for a wide variety of conditions. Its reliable launch characteristics and dynamic flight behavior ensure enjoyable flights even on long workdays. Practical features like the Big Ears aid and adjustable brake pulley height provide optimal handling and a relaxed flight experience. The robust construction, with reinforced stress points, guarantees that you’ll benefit from this wing for years to come.
Use it in combination with the Skywalk Guide and Skywalk Guest harnesses, and the Skywalk Flashbag
- Specifically designed for professionals, based on pilot feedback
- Weight range of 100-240 kg: Versatile use across three sizes
- Safe launch characteristics: Stable and easy takeoff
- Practical features: Big Ears aid and adjustable brake pulley height for optimal handling
- Robust construction: Reinforced at high-stress points for long-lasting durability
DETAILS
Launch
The proven line setup simplifies and accelerates launch preparation by minimizing tangling during sorting.
The JOIN‘T5 inflates smoothly and steadily without any risk of uncontrolled overshooting.
With its strong performance, the wing quickly lifts the tandem team off the ground, ensuring a safe and efficient takeoff.
Handling
In the air, the JOIN‘T5 impresses with its precise responsiveness, even in the upper, ergonomic working range. The low brake pressure is energy-saving—ideal for long workdays.
The wing offers a playful handling with finely adjustable bank angles. Thanks to its direct handling, dynamic maneuvers like wingovers become a true pleasure for both pilot and passenger. The brake pressure increases linearly, becoming noticeably firmer up to the stall point, providing a secure and controlled flying experience.
Performance
The excellent glide performance of the JOIN‘T5 not only enables XC flights with passengers but also allows the wing to lift off quickly from the ground. Furthermore it enables a strong flare to reduce momentum during landing, ensuring a smooth and safe touchdown.
Extreme flight
The JOIN‘T5 demonstrates highly manageable and forgiving flight characteristics in extreme flight conditions.
Due to its wide weight range, it responds slightly slower in the lower weight range and the pilot may notice a delayed reaction.
– B-Stall
In the upper weight range, the forces are quite high, making the B-stall more challenging.
– Ohren anlegen
The split A-risers on the JOIN‘T5 make performing big ears particularly easy. An integrated CLAMCLEAT on the riser allows for fixing the lines.
To use this feature, simply pull the cover down and the outer A-line can be secured in the cleat. This allows the JOIN‘T5 to maintain in big ears posi- tion for extended periods, saving energy and freeing the pilot’s hands. After completing the maneuver, the cover should be pushed back up to pre- vent any lines from tangling.
RISER
Brake Pulley – adjustable position
The brake pulley height can be optimally adjusted to suit the pilot’s ergonomics.
A second loop positioned slightly lower on the riser provides an alternative mounting option for the brake pulley. When the pulley is attached in this lower position, the brake line must be extended by 5cm.
CAUTION!
The extended brake travel will impact the wing’s flight characteristics. In challenging takeoff conditions, it is especially important to note that the wing will require increased brake input.
Trimmer System
The JOIN‘T5 features an efficient trimmer system with a 15 cm adjustment range, enabling a substantial speed increase.
When flying the JOIN‘T5 in the lower weight range, we recommend slightly opening the trimmer for opti- mal flight behavior.
The trimmer strap is easily secured with the EASYFIX magnet. To release, simply slide the magnet from top to bottom, allowing for quick and effortless adjustments.
technical data
materials
Upper sail front – Myungjin MJ40
Upper sail – Myungjin MJ32 MF
Bottom sail – Myungjin MJ32 MF
Profiles – Porcher Skytex 40 hard
Diagonals – Porcher Skytex 40 hard
Straps – Porcher Skytex 40 hard
The JOIN‘T5 is specifically designed for professional tandem use, constructed with robust materials to withstand intensive demands. An additional fabric layer reinforces the leading edge over the rigid foils, offering exceptional protection in case the leading edge hits the ground. This feature enhances durability and reliability for daily operation
LINES
Main lines Liros TSL 500, NTSL 350/280, PPSL 120
Middle lines Liros TSL 280/190, DSL 70
Top lines Liros PPSL 120, DSL 70
Main brake line Liros DFLP 200/32, PPSL 180
Top lines Liros PPSL 120, DSL 70
Main brake line Liros DFLP 200/32, PPSL 180
Brake lines Liros PPSL 120, DSL 70
Stock code: SKYW-P-JOINT5
